The Piccolo 45 is a special micro fixture that measures 0.26 x 0.26 in. (6.6 x 6.6 mm) with a flat milky lens presented at 45° to create fine lines of light in tight spaces, corners and under cabinets. It is sold in custom lengths ranging from 2.04 in. (51.7 mm) to 6 ft. 5.75 in. (1974.7 mm) in increments of 1.52 in. (38.46 mm). The Piccolo 45 features an IP20 micro RibbonLyte that provides 90+ CRI in six available CCTs ranging from 2200K to 4000K.
Features
3.0 W/ft (9.8 W/m)
Sold in custom lengths up to 6 ft 5.75 in. (1974.7 mm)
Flat milky lens
1.52 in. (38.5 mm) cut lengths
55 LEDs/ft (182 LEDs/m)
37 lm/W
90+ CRI
IP20 for indoor use
Title 24, JA8 compliant
TM66 assessed (see downloads for details)
Width: 0.26 in. (6.6 mm)
Height: 0.26 in. (6.6 mm)
Internal Width: 0.12 in. (3 mm)
Beam Angle: 120° beam angle presented at 45°
Interior / Exterior: Interior only
Lens
