Too often, time constraints can force a designer to settle on a lower-quality product. The newly updated Acolyte 5-Day QuickShip program means that doesn’t have to happen to you. We know deadlines can’t wait — but you shouldn’t have to sacrifice your lighting design or LED product quality for speed. That’s where the Acolyte QuickShip program comes in. We keep a healthy inventory of a wide selection of our most popular products so they are available for immediate custom assembly. Our commitment to customer satisfaction means we can meet your needs and have your custom fixtures ready to ship anywhere across the U.S. within five days.
Product Availability
Prompt Delivery
Tracked Shipments
Customer Support
PROGRAM TERMS
– A specific PO labeled “QUICKSHIP” is required for QUICKSHIP orders.
– Orders containing products not offered in the QUICKSHIP Program must be submitted separately.
– Orders received before 12:00pm EST are counted as Day 1.
– Orders will ship from our facility within 5 days of Day 1 (excluding weekends & holidays).
– QUICKSHIP orders may not be cancelled at any time.
– Maximum ordering length of a single item is 200 feet per order.
– Program terms are in conjunction with Acolyte’s Standard Terms & Conditions
See our QuickShip catalog for more details.
Quickship Products
RibbonLyte (LED tape)
0.75 W/ft (2.5 W/m)
2700K, 3000K, 3500K, 4000K
101 lm/ft at 4000K
49 LEDs/ft (160 LEDs/m)
Cut every 1.97 in. (50 mm)
Max run length IP20: 49 ft. (15 m)
Title 24, JA8 compliant
0.75 Static White Series 2
1.5 W/ft (4.9 W/m)
201 lm/ft @4000K
2700K, 3000K, 3500K, 4000K
49 LEDs/ft (160 LEDs/m)
Cut every 1.97 in. (50 mm)
Max run length IP65:
32 ft. 8 in. (10 m)
Title 24, JA8 compliant
1.5 Static White Series 2
3.0 W/ft (9.8 W/m)
2700K, 3000K, 3500K
411 lm/ft at 3500K
49 LEDs/ft (160 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length IP65/IP68:
32 ft. 8 in. (10 m)
Title 24, JA8 compliant
3.0 Static White Series 2
4.4 W/ft (14.4 W/m)
585 lm/ft @4000K
2400K, 2700K, 3000K, 3500K, 4000K
49 LEDs/ft (160 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length: 28 ft. 4 in. (8.64 m)
Title 24, JA8 compliant
4.4 Static White Series 2
5.0 W/ft (16.4 W/m)
675 lm/ft @3500K
2700K, 3000K, 3500K, 4000K
68 LEDs/ft (224 LEDs/m)
Cut every 1.41 in. (35.7 mm)
Max. run length IP20:
33 ft. 4 in. (10.1 m)
Max. run length IP65, IP68:
32 ft. 8 in. (10 m)
Title 24, JA8 compliant
5.0 Static White Series 2
6.0 W/ft (19.7 W/m)
792 lm/ft @3500K
2700K, 3000K, 3500K, 4000K
68 LEDs/ft (224 LEDs/m)
Cut every 1.41 in. (35.7 mm)
Max. run length: 28 ft. (8.5 m)
Title 24, JA8 compliant
6.0 Static White Series 2
3.0 W/ft (9.8 W/m)
2400K, 2700K, 3000K, 3500K, 4000K
43 LEDs/ft (140 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length: 28 ft. (8.5 m)
Title 24, JA8 (2200K-4000K)
3.0 Static White Micro
1.0 W/ft (3.3 W/m)
90 lm/ft
2000K-6500K
42 LEDs/ft (140 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length: 32 ft. 8 in. (10 m)
1.0 Variable White Series 2
3.0 W/ft (9.8 W/m)
240 lm/ft
2000K-6500K
42 LEDs/ft (140 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length: 32 ft. 8 in. (10 m)
3.0 Variable White Series 2
6.0 W/ft (19.7 W/m)
440 lm/ft
2000K-6500K
42 LEDs/ft (140 LEDs/m)
Cut every 1.97 in. (50 mm)
Max. run length: 32 ft. 8 in. (10 m)
6.0 Variable White Series 2
5.2 W/ft (17 W/m)
2900K/2000K
36 LEDs/ft (120 LEDs/m)
288 lm/ft (945 lm/m) at 100%
Cut every 3.94 in. (100 mm)
Max. run length: 16 ft. 4 in. (5 m)
Warm Dim
3.0 W/ft (9.8 W/m)
87 lm/W
15 LEDs/ft (50 LEDs/m)
Bends up to 90 degrees
Cut every 4.84 in. (123 mm)
Max. run length: 39 ft. 4 in. (12 m)
Static White Matrix
3.0 W/ft (9.8 W/m)
15 LEDs/ft (50 LEDs/m)
110 lm/ft (360 lm/m)
Bends up to 90 degrees
Cut every 4.84 in. (123 mm)
Max. run length: 39 ft. 4 in. (12 m)
RGB Matrix
3.0 W/ft (9.8 W/m)
36 LEDs/ft (120 LEDs/m)
124 lm/ft (407 lm/m) (all)
43.4 lm/W (all)
Width: .73″ (18.5 mm)
Cut every 1 ft (304.8 mm)
Max. run length: 100 ft. (30.48 m)
RGB Direct AC RibbonLyte
4.4 W/ft (14.4 W/m)
18 LEDs/ft (60 LEDs/m)
165 lm/ft (541 lm/m) at 100%
37 lm/W
Cut every 3.94 in. (100 mm)
Max. run length: 19 ft. 7.9 in. (6m)
4.4 RGB
4.4 W/ft (14.4 W/m)
236 lm/ft (774 lm/m) at 100%
RGBW/A
18 LEDs/ft (60 LEDs/m)
Cut every 6.55 in. (166.4 mm)
Max. run length: 19 ft. 7.9 in. (6m)
4.4 RGBW/A
5.5 W/ft (18 W/m)
279 lm/ft (915 lm/m) at 100%
RGBW/A
18 LEDs/ft (60 LEDs/m)
Cut every 3.94 in. (100 mm)
Max. run length: 19 ft. 7.9 in. (6m)
5.5 RGBW/A 4-in-1
Channel
AS1
AS2
AS3
AS6
AS20G
WH35
Width: .77 in. (19.6 mm)
Height: .74 in. (18.8 mm)
Internal: .67 in. (17.1 mm)
Beam Angle: 120
Milky lens
AT4
Width: .77 in. (19.6 mm)
Height: .74 in. (18.8 mm)
Internal: .66 in. (16.8 mm)
Beam Angle: 120
Milky lens
AT5
AW35
AC1
AC2
AC3
AR1
AR2
W31
Driverless (120 VAC)
3.0 W/ft (9.8 W/m)
36 LEDs/ft (120 LEDs/m)
124 lm/ft (407 lm/m) (all)
43.4 lm/W (all)
Width: .73″ (18.5 mm)
Cut every 1 ft (304.8 mm)
Max. run length: 100 ft. (30.48 m)
RGB Direct AC RibbonLyte
1.3″ high in 6 lengths
9″, 3W, 89.3 lm/W
13.6″, 5W, 92 lm/W
22.63″, 9W, 94.4 lm/W
34.5″, 14W, 92.9 lm/W
46.3″, 18W, 92.8 lm/W
58″, 22W, 90.9 lm/W
2700K, 2900K, 4100K
Rigid AC
Wall Washers/Grazers
6W, 8.46″ (215 mm)
12W, 16.1″ (410 mm)
18W, 23.8″ (605 mm)
36W, 46.9″ (1190 mm)
3000K
900.12 lm/ft (2952.4 lm/m)
Dimmable
Mini Linear
Mini Linear RGBW
Controllers
5-15 VDC input
8 USB dry contact ports
Adjust color, brightness, saturation
Control 36 preset scenes
Programmable
Touch capacitive
2 universes of 512 DMX channels
1 Zone DMX Wall Controller
5-6 VDC input
Adjust color, brightness, saturation
Control 200 preset scenes
SD card storage
Programmable
Touch capacitive
2 universes of 512 DMX channels
5 Zone DMX Wall Controller
5-6 VDC input
Adjust color, brightness, speed
Control 500 preset scenes
SD card storage
Programmable
Touch capacitive
2 universes of 512 DMX channels
10 Zone DMX Wall Controller
1 zone
DMX 512 signal
Manage scenes and moods
Control color blends, brightness
Mix white CCTs with RGB
Touch capacitive glass
RGB+RGBW
2.94″ x 4.72″ (75 x 120 mm)
Glass Touch DMX Wall Controller
4 zones
3 scenes per zone
Touch color wheel
RGB or RGBW
Switch and dimming functions
Control to 100 ft. (30 m)
Control multiple interfaces
4 Zone RGBW RF Remote
3 scenes per zone
Touch color wheel
Variable (tunable) white
Switch and dimming functions
Control brightness/intensity
Control to 100 ft. (30 m)
Control multiple interfaces
4 Zone Variable White RF Remote
Linear-slide dimmer
Compatible with:
0-10V Dimming Module
30 mA max control current
2.94″ x 4.69″ (75 x 120 mm)
Lutron Diva Dimmer
Set DMX address freely
IP67 rating for outdoor use
Switchable Master/Decoder
Output for DC100-240V
3 Channel LED strip
2.9″ x 5.93″ x 1.38″
73.6 x 150.5 x 35 mm
High Voltage 3 Channel Waterproof DMX Interface
4 x 5A outputs
12-36VDC input and output
480 W total power w/24V driver
Constant voltage
7″ (178 mm) x 1.1″ (46 mm)
4 Channel RF Interface
3 DMX input styles
Adjustable PWM frequency
96 W max. power output
8A max. output per channel
2.87″ x 6.45″ x 1.49″
73 x 164 x 38 mm
DMX terminator req’d
5 Channel DMX Interface
Drivers (Power Supplies)
Constant voltage
120-277 VAC
Dimming range: 0.1% to 100%
UL 8750 and UL 1310 approved
UL rated for wet, damp, dry
8.66″ x 3.72″ x 1.57″
220 x 94.5 40 mm
0-10V Dimmable 96W Waterproof Driver
Three 96W Class 2 outputs
120-277 VAC
Dimming range: 0.1% to 100%
UL 8750 and UL 1310 approved
UL rated for wet, damp, dry
11.85″ x 5.51″ x 1.77″
301 x 140 x 45 mm
0-10V Dimmable 288 Watt Waterproof Driver
120V AC
Dry or damp location
UL 8750 Listed
Dim to 1%
Line voltage dimming
or ecosystem dimming
4″ x 4″ x 2.62″
98.8 x 98.8 x 40.4 mm
24V Lutron Hi-lume Driver
120-277 VAC
24 V output
IP65, UL 8750 approved
UL Listed enclosure
Built-in junction boxes
12.1″ x 2.36″ x 1.4″
308 x 60 x 35 mm
