0-10V Dimmable 90W VW/WD Driver

The 0-10V Dimmable 90W VW/WD Driver provides smooth, flicker-free dimming down to 0.1% before darkness, softly tuning CCTs to ensure a quality lighting experience. Compatible with any standard 0-10V dimming system, this UL Listed 24V Class 2 driver is an all-in-one driver/module solution for Variable White and Warm Dim lighting (and Static White dimming too) that eliminates the need for extra components. It uses an integrated junction box with separate input and output wiring compartments.


0-10V Constant Voltage driver
Compatible with 0-10V dimming systems
Use for Variable White, Warm Dim or Static White
Meets CEC Title 24 Section JA8 flicker requirements
Superior flicker-free dimming to 0.1%
UL Listed Class 2 driver
Integrated junction box
Wiring compartments with knockouts for safety

Voltage: 24V

Dimming: Dimmable

IP Rating: 23
